Rotary Type Ampoule Washing Machine
Kambert KGRW 20×3 is the latest addition to our range of high quality Rotary Ampoule Washing Machine. Absolute cleanliness and hygiene are paramount in pharmaceutical filling and packaging processes and this becomes of even more importance when you consider injectables filled into glass ampoules. Each ampoule must be absolutely sterile before it goes into the sterile filling area. Kambert, the leader in high technology pharmaceutical machinery offers a high precision ampoule washing machine that meets today’s high standards of sterility and hygiene.
Internal Cleaning
The KGRW 20×3 is equipped with 6 internal cleaning stations and each station has 6 cleaning needles making up a total of 36 cleaning needles. Each cleaning station is supplied via a pipe connected to the cleaning media-making washing area. This not only reduces the risk of particle generation, but also simplifies maintenance and cleaning efforts while saving time.
External Cleaning
The 3 external cleaning stations mounted in a stationary position above the ampoule can be easily adjusted for a specific height, angle and lateral position. Each cleaning station receives cleaning media-making through a pipe connected to the cleaning media-making washing area.
Cleaning Media Saving Principle
WFI, Purified water and air cleaning station are synchronized with the ampoule by reciprocating motion. Design is such that these media are put to use only when needles motion in forward direction. WFI consumption is further reduced by collecting the WFI in re-circulating water tank to be used later on in the pre-washing station. The ideal output of the machine is maximum upto 18000 ampoules/hr. Kambert also offers Change Part sets for rotary ampoule washing machine.
STANDARD FEATURES
- Contact parts SS 316
- PLC with HMI Control with 6″ touch screen
- Out feed counting sensor
- Digital pressure gauges
- Re-Circulating water tank with Multi stage centrifugal pump & Heater
- Polycarbonate upper guards with interlock
- Filter housing without cartridge
- 6 Internal & 3 External washing cycle (Recycle / Purify / WFI / Air)
- Any one size of change part fitted with machine
OPTIONAL FEATURES
- Contact parts SS 316L
- PLC with HMI Control & Printing facility with 10″ Touch screen
- Additional water tank with Pump for WFI
- Additional water tank with Pump for Purified
- Automatic draining system
- Change part set
| MODEL | KGRW-20×3 | KGRW-20×4 | |
|---|---|---|---|
| Number of Grippers | 60 | 80 | |
| Max Rated Output Ampoule / Minute* | 300 | 400 | |
| Re-Cycle Water Tank Capacity | 50 Ltr | ||
| Ampoule Range | Diameter | 9 to 17 | |
| Height (Open Ampoule) | 60 to 105 | ||
| Electric motor | Main motor | 1.5 hp | |
| Recycle-Pump | 1.5 hp | ||
| Conveyor motor | 0.25 hp | ||
| Utility | Electric | 3 Phase, 415V, 50 Hz | |
| Power | 7.6 / 10.7 kW/hp | ||
| Compressed air** | 20 CFM at 4Kg/cm2 | 25 CFM at 4Kg/cm2 | |
| Water** | Re-Cycle Water : 200 to 250 Ltr/Hour at 3 Kg/cm2 | Re-Cycle Water : 300 to 350 Ltr/Hour at 3 Kg/cm2 | |
| (If use WFI Water at Re-Cycle station than no water req.) | (If use WFI Water at Re-Cycle station than no water req.) | ||
|
Purified Water : 200 to 250 Ltr/Hour at 3 Kg/cm2
WFI Water : 200 to 250 Ltr/Hour at 3 Kg/cm2 |
Purified Water : 300 to 350 Ltr/Hour at 3 Kg/cm2
WFI Water : 300 to 350 Ltr/Hour at 3 Kg/cm2 |
||
| Overall Dimensions-mm |
2500W x 1650D x 1640H (For Machine) |
2360W x 2250D x 1640H (For Machine) |
|
|
1100W x 940D x 1050H (For Water & Air Unit) |
|||
* Depending upon the ampoules size & quality.
** Depending upon the ampoule size.
Kambert reserves right to make any changes in the catalogue without intimation.
